Description

Limits of use

• Liquid temperature: -10°C – + 110°
• Power: single-phase 220V/50Hz.
• Max .working pressure :1Obar.

Features

• Suitable for any installation location with a horizontal shaft, terminal box in 3-6-9-12 o’clock

• Three pre selectable speed stages for load
• Use of wet rotor motor technology to assure super
• Suitable for boosting water/glycol its proportion shall not exceed 1:1.

Application

• For boosting hot water in the house
• For boosting hot water in air-conditioning .solar system, boilers, water heaters, etc.
• For boosting hot water in machinery and equipment

Components & Materials

• Pump body :Cast iron(electrophoretic paint).
•  impeller: Plastic(PP).
• Bearing: Ceramic.
• Shaft: Ceramic.

Installing Position

• Horizontally installed.
