Marquis 5"-Borehole 5.5HP Submersible Pump, 5SWm 30-5

Marquis 5″-Borehole 4HP Submersible Pump, 5SWm 30-4

SKU: 5SWm 30-4 Categories: 5" Borehole Submersible Pump, Water Pump, Marquis, Borewell Submersible Pump

Original price was: ৳ 42,000.00.Current price is: ৳ 39,900.00.

Technical Specifications

Power: 4.00HP or 3.00KW
Phase: ~1 or 220V
Water Flow: 100-700 LPM
Head: 38-12 meters
Pump Diameter: 5″
Delivery Diameter: 3″

WHAT’S IN THE PACKAGE – Pump, Motor, ~27m Power Cable, Control Box, Warranty Card, User Manual, etc.

Out of stock

Add to Wishlist

Description

Performance Data

m³/hr	0	6	12	18	24	30	36	42
Lit/min	0	100	200	300	400	500	600	700
Head (m)	39	38	35	33	29	25	19	12

Applications

For water supply from wells or reservoirs
For domestic use
For civil and industrial applications
For garden use and irrigation

Operating Conditions

Maximum fluid temperature up to +35C
Maximum sand content 0.25%
Maximum good diameter 6″

Motor and Pump

Rewindable motor
Single Phase or 220-240V/50Hz
Equip with a start control box or digital auto-control box
NEMA dimension standards
Curve tolerance according to ISO 9906

Options on Request

Special mechanical seal
Other voltages or frequency 60Hz

Warranty

24 (twenty-four) months service warranty. The first 12 (times) months were on a motor warranty and two years of service warranty.

Additional information

Weight	28.0 kg
Dimensions	50 × 6.5 × 6.5 in
